Engineered for superior durability and efficiency in logistics and postal operations. With its robust construction, this belt offers exceptional durability, ensuring reliable performance under heavy loads and continuous use.
Key Features:
Custom colors, thicknesses, profiles and special features available upon request, please contact us for more information.
| TYPE # | |
| SOLID150/0.1+1.0/4.0B | |
| REFERENCE # | |
| GENERAL CHARACTERISTICS: | |
| SUITABLE FOR MOST OF LINES AND PRODUCTS | |
| GENERAL TRANSPORT | |
| TECHNICAL CHARACTERISTICS : | |
| Total Thickness | 4.0 mm |
| No. of Plies | 1 |
| Fabric | Interwoven |
| Weft | Flexible |
| Weight | 4.8 kg(s)/㎡ |
| Working Temperatures | -10 ºC to + 70 ºC |
| 1. Top cover | |
| Thickness | 1.0 mm |
| Material | PVC |
| Color | Black (B) |
| Surface | Glossy |
| Hardness | 80 ShA |
| 2. Internal layer(s) | |
| Material | - |
| Color | - |
| 3. Bottom cover | |
| Thickness | 0.1mm |
| Material | PVC |
| Color | Black (B) |
| Surface | Fabric with Impregnation |
| Hardness | - |
| Anti-static Yarn | - |
| BELT TENSION: | |
| Tensile Strength(N/mm) | 150 |
| Max. Suggested Load(N/mm) | 22 |
| Working Load 2% Elongation(N/mm) | 24 |
| FRICTION COEFFICIENTS ON: | |
| Smooth Stainless Steel | 0.42 |
| REMARKS | |
| Max. Manufacturing Width | 3000mm |
| Standard Width | 2000mm, 3000mm |
| MINIMUM PULLEY DIAMETERS: | |
| Front Flexing | 65 mm |
| Back Flexing | 80 mm |
| CONVEYOR FRAME: | |
| Horizontal Rollers | Yes |
| Slider bed | Yes |
| Troughed application | Yes |
| SPECIAL CHARACTERISTICS: | |
| Food Grade | No |
| Oil Resistant | No |
| Flame Retardant | No |
| Surface Antistatic | No |
| Cold Resistant | No |
| JOINING INSTRUCTIONS: | |
| Finger Joint | Fastener |
| Welding Temperature（°C） | 175 °C ± 10 °C |
| Pressure | 2 bar |
| Cooling | Cool Immediately |
