Made from premium TPU material, these blankets offer superior surface finish, ensuring consistent quality with every print. Designed for high chemical resistance, they stand up to harsh conditions often found in the printing industry, offering long-lasting durability.
Custom colors, thicknesses, profiles and special features available upon request, please contact us for more information.
| TYPE # | |
| EHM220/1:0+1.0M/2.15BPU/AS | |
| REFERENCE # | |
| ENU-20EXBD Print 6552-2.15AE Print 6646-2.15E |
|
| GENERAL CHARACTERISTICS: | |
| ROTARY TEXTILE PRINTING | |
| TECHNICAL CHARACTERISTICS : | |
| Total Thickness | 2.15 mm |
| No. of Plies | 1 |
| Fabric | High Grade Polyester |
| Weft | Rigid |
| Weight | 2.5 kg(s)/㎡ |
| Working Temperatures | -10 ºC to + 70 ºC |
| 1. Top cover | |
| Thickness | 1.0 mm |
| Material | TPU |
| Color | Black (B) |
| Surface | Matt |
| Hardness | 93 ShA |
| 2. Internal layer(s) | |
| Material | TPU |
| Color | Black (B) |
| Fabric | - |
| 3. Bottom cover | |
| Thickness | - |
| Material | - |
| Color | Natural |
| Surface | Fabric with Impregnation |
| Hardness | - |
| Anti-static Yarn | Yes |
| BELT TENSION: | |
| Tensile Strength(N/mm) | 220 |
| Max. Suggested Load(N/mm) | 18 |
| Working Load 1% Elongation(N/mm) | 20 |
| FRICTION COEFFICIENTS ON: | |
| Smooth Stainless Steel | 0.16 |
| REMARKS | |
| Max. Manufacturing Width | 4000mm |
| Standard Width | 2000mm, 3000mm |
| MINIMUM PULLEY DIAMETERS: | |
| Front Flexing | 30 mm |
| Back Flexing | 50 mm |
| CONVEYOR FRAME: | |
| Horizontal Rollers | Yes |
| Slider bed | Yes, Flat |
| Troughed application | No |
| SPECIAL CHARACTERISTICS: | |
| Food Grade | No |
| Oil Resistant | Yes |
| Flame Resistant | No |
| Surface Antistatic | No |
| Cold Resistant | No |
| JOINING INSTRUCTIONS: | |
| Finger Joint | Yes |
| Welding Temperature（°C） | 160 ºC ± 10 ºC |
| Pressure | 2 bar |
| Cooling | Cool Immediately |
